Emergency Bulkheads
Emergency Bulkheads Product Page
Reliable LED Emergency Lighting for Commercial, Industrial and Public Buildings
Emergency Bulkheads provide automatic backup illumination when normal power fails. They are widely installed in corridors, staircases, commercial buildings, industrial facilities and public areas where continuous lighting is required for safe evacuation. Our Emergency Bulkhead solutions are developed for original equipment manufacturing supply, project applications and distributor markets, with options covering maintained and non-maintained operation, different battery capacities, protection ratings and mounting configurations.
Emergency Bulkhead Lights combine LED lighting technology, emergency control electronics and rechargeable battery systems in a compact wall-mounted or ceiling-mounted housing. During normal operation, the fixture works according to the configured lighting mode. When power interruption occurs, the emergency control system automatically switches to battery power and maintains illumination for the required emergency duration.
Automatic Emergency Switching: Integrated emergency control circuitry detects mains power failure and activates battery-powered lighting automatically.
LED Light Source: High-efficiency LED modules provide stable illumination with lower energy consumption compared with traditional fluorescent emergency fixtures.
Multiple Operating Modes:
- Maintained mode: Light operates continuously during normal conditions and emergency situations.
- Non-maintained mode: Light activates only during power failure.
- Durable Housing Design: The enclosure can be configured with materials suitable for commercial and industrial environments, including impact-resistant and weather-resistant options.
- Easy Installation: Designed for common electrical installation methods, reducing installation time for contractors and maintenance teams.
Product Specifications & Compliance
|
Parameter |
Options |
|
Light Source |
LED |
|
Installation Type |
Wall mounted / Ceiling mounted |
|
Operation Mode |
Maintained / Non-maintained |
|
Emergency Duration |
1 hour / 3 hours options |
|
Input Voltage |
AC standard options available |
|
Battery Type |
Rechargeable battery options |
|
Housing Material |
PC / ABS / Custom materials |
|
Protection Rating |
IP20 / IP44 / IP65 options |
|
Application |
Indoor / Commercial / Industrial |
|
Certification & Standards |
CE, RoHS, ISO 9001 certified manufacturing |
Emergency Bulkhead Types
Maintained Emergency Bulkhead
Maintained models provide continuous illumination during normal operation and remain active during power failure.
Typical applications: Hotels, shopping centers, public buildings, commercial corridors.
Non-Maintained Emergency Bulkhead
Non-maintained models remain off during normal power supply and activate only when the main power fails.
Typical applications: Industrial facilities, warehouses, back-of-house areas, emergency routes.
IP65 Waterproof Emergency Bulkhead
Ingress protection-rated models are designed for environments where protection against dust and water exposure is required.
Typical applications: Parking areas, factories, outdoor covered areas, utility rooms.
Applications
Commercial Buildings
Used in office corridors, stairways, reception areas, and public passages to provide reliable emergency illumination during unexpected power interruptions.
Industrial Facilities
Suitable for manufacturing plants, warehouses, production areas, and maintenance zones designed for demanding operating environments.
Hospitality and Public Facilities
Commonly installed in hotels, schools, hospitals, and residential buildings to support emergency evacuation requirements and building safety systems.
Manufacturing and Quality Control
Emergency lighting reliability depends heavily on electronic components, battery performance and assembly consistency. Our manufacturing process focuses on:
LED Module Inspection
Checking light output consistency, electrical performance, and component reliability.
Battery Testing
Testing battery systems for charging performance, discharge duration, and safety performance through rigorous laboratory cycle tests.
PCB Assembly Control
Inspecting electronic control boards for component placement, soldering quality, and functional performance.
Aging Test
Subjecting finished products to operational testing to verify lighting stability, emergency switching function, and long-term operating reliability.
For distributors, wholesalers and project suppliers, customization options include:
Product Design: Housing appearance, size adjustment, mounting structure.
Electrical Configuration: Battery capacity, emergency duration, voltage requirements.
Branding
Logo printing, packaging design, product labeling.
Market Requirements
Support for different regional technical documentation packages.
Commercial Terms
Minimum Order Quantity (MOQ) and production lead times are structured flexibly to support both trial orders and large-scale project rollouts.
How to Select the Right Emergency Bulkhead
Application Environment: Indoor commercial areas and industrial environments may require different protection levels.
Emergency Duration Requirement: Select battery capacity according to local regulations and project specifications.
Maintained or Non-maintained Operation: Choose based on whether continuous lighting is required.
Installation Conditions: Consider mounting location, available wiring, and environmental exposure.
Compliance Requirements: Confirm required certifications and standards before project approval.
